الاسم التجاري:	ATMC
الـ MOQ:	1 قطعة
السعر:	inquiry
تفاصيل التعبئة:	حالة الخشب الرقائقي القياسية للتصدير
شروط الدفع:	خطاب الاعتماد، د/أ، د/ف، تي/تي

معلومات مفصلة

وصف المنتج

معلومات مفصلة

بناء:

وصف النمط:

شبكة × العدد (لتر/سم):

قطر الالتواء (مم):

قطر اللحمة (مم):

مواد الاعوجاج / اللحمة:

نفاذية الهواء:

الفرجار (مم):

كسر القوة:

الوزن (GSM):

مؤشر دعم الألياف (FSI):

مؤشر الصرف (DI):

منطقة مفتوحة:

لون القماش:

إبراز:

Double layer paper forming fabric

Eight over sixteen shed weave fabric

High fiber retention drainage fabric

وصف المنتج

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

The PRINT DAL67816SM is a double layer forming fabric engineered with a fine eight shed paper side weave over a sixteen shed wear side construction. The paper side features extra cross direction support yarns that deliver high fiber retention, while the robust wear side incorporates a pronounced CD crimp with large diameter yarns for extended life potential. This unique combination achieves both high fiber support and very high drainage capacity within a single fabric design. The large diameter CD crimp on the machine side effectively protects MD warp yarns from abrasion and increases wear yarn mass. The robust construction withstands high MD loads and resists CD ridging, making this fabric suitable for printing and writing paper, light weight kraft, and board grades.

Key Features

Eight over sixteen shed double layer weave construction
Fine mesh eight shed paper side with extra CD support yarns
Sixteen shed wear side weave for good service life
High fiber support for excellent retention performance

Product Parameters

Product Name	Forming Fabric PRINT DAL67816SM
Material	Polyester monofilament
Function	Paper Machine
Application	Printing & Writing Paper, Newsprint Paper, etc.
Technical	1/1.5/2/2.5/3 layers forming fabric
Width	Customized
Weigh	Customized
Fabric Color	Customized

Product Images

Top Side View

Bottom Side View

Application

Printing & Writing Paper, Newsprint Paper, etc..
